With the increasing popularity of drones, incidents like this occur frequently. To address the issue of drones flying blindly and erratically, our company has specially developed and produced the 710A handheld drone jamming device. This device can interfere with and shield all satellite positioning signals (1.2G, 1.5G), including GPS/GLONASS/Galileo; it can also jam the commonly used drone frequencies of 433, 915, ISM 2.4G, and ISM 5.8G, forcing the drone's remote control, image transmission, and positioning signals to be interrupted, achieving the effect of forced landing/return/hovering. The interference distance can reach up to 1000 meters.
| Technical Specifications | Details |
|---|---|
| Countermeasures Frequency | 430-450MHz, 840-960MHz, 1170-1280MHz, 700-840MHz, 1500-1620MHz, 2400-2500MHz, 5150-5350MHz, 5350-5550MHz, 5715-5860MHz |
| Number of Signal Channels | 8 channels (simultaneous output of jamming signals) |
| Operating Mode | Wireless Electronic Interference Suppression |
| Jamming Signal Output Power | 400M (15W), 900M (15W), 1.2G (15W), 1.4G (15W), 1.5G (15W), 2.4G (30W), 5.2G (30W), 5.5G (15W), 5.8G (30W) |
| Countermeasures Distance | 1~2km (varies with environment and model) |
| Countermeasures Method | Directional mode |
| Automatic Start Time | <1 second |
| Target Object | Drone image transmission, flight control link, navigation signal |
| Power Supply | Built-in rechargeable battery (25AH) |
| Size | 710370205 mm |
| Weight | About 9kg |
Product Features:
1. Independently developed and produced, reasonably priced, with sufficient power.
2. Cuts off all signal communication between the drone and the controller, forcing the drone's remote control to malfunction.
3. Suppresses the drone's ground controller from receiving aerial video and images.
4. Cuts off the drone's navigation and positioning system, forcing the drone to land, hover, or return.
5. Equipped with an efficient rechargeable battery; once fully charged, it can be used continuously for 2 hours.
6. Customization is available upon special request; installation and operation are very convenient.
7. The main body of the device is made of a metal baked enamel case, which is resistant to impact and pressure, making it sturdy and durable.
8. The combination of an efficient cooling fan and heat sinks inside ensures stable performance and an extended lifespan.
